NT1065_USB3 RF IC EVALUATION KIT

NT1065_USB3 is an evaluation platform for performance and capabilities demonstration of NT1065: 4-channel GPS/GLONASS/Galileo/BeiDou/NavIC/QZSS L1, L2, L3, L5, E1, E5a, E5b, E6, B1, B2, B3 band RF Front End. It includes USB3 data converter thus allowing an user to process captured satellite signals on a PC. Data rate is configurable and may be as high as 800 Mbps (200 Mbps per channel)

KEY FEATURES

IO ports:

• Every channel individual RF input
• External reference frequency input (TCXO)
• USB 3.0 output

On-board reference frequency sources:

• 10 MHz 0.28ppm high-stability TCXO

Additional modules:

• 1 to 4 RF splitter
• 2 to 4 RF splitter
• 4-channel RF preselector

Comprehensive software and manual:

• GUI for NT1065 registers access (Windows 7/8/8.1/10 and Linux Ubuntu 16.04 compatible)
• GUI for USB3 data capture
• Configuration examples
• Complete NT1065 user guide
• Database of reference design
